What is the difference between U-profile and TH-profile brass press fittings?

Introduction to press profiles
Different press profiles exist for different systems. U-profile and TH-profile are two common types. They are not interchangeable with each other. Brass press fittings must match the correct profile. Example: using a U-profile jaw on a TH fitting causes leaks .

What is a press profile?
A press profile is the jaw's inner geometry. It deforms the fitting in a controlled way. The profile ensures correct seal compression. Brass press fittings rely on precise profile matching. Example: radii, shoulder positions, and flank angles all vary by profile .

U-profile design characteristics
U-profile has a distinct U-shaped groove. It is commonly used for Uponor systems. This profile works with multilayer and plastic pipes. Brass press fittings with U-profile are popular in Europe. Example: Uponor, Unicor Unipipe, and Wavin Tigris use U-profile .

TH-profile design characteristics
TH-profile has a more rounded pressing contour. It is a modified version of older profiles. This geometry avoids over-compression of fittings. Brass press fittings with TH-profile are widely available. Example: Viega, Unipipe, Wavin, and Henco systems use TH-profile .

Sealing mechanisms compared
Both profiles use O-rings for sealing. The sealing principle is identical between them. However, the compression travel distance differs. Brass press fittings achieve sealing through controlled deformation. Example: a double O-ring design is common on both types .

Compatibility with pipe materials
U-profile works with PEX and multilayer pipes. TH-profile also works with multilayer composite pipes. The pipe material must be malleable enough. Brass press fittings both require specific pipe compatibility. Example: thin-walled stainless steel often uses TH-profile .

Geographic distribution patterns
U-profile is most common in Europe and Africa. TH-profile is popular in North America. Some European countries also use TH-profile. Brass press fittings availability varies by region. Example: a fitting bought in Germany may be TH, but in Italy may be U .

Tool compatibility requirements
Each profile needs its own pressing jaws. U-profile jaws cannot press TH fittings. TH-profile jaws cannot press U fittings. Brass press fittings require manufacturer-approved tools. Example: a Viega press tool with TH jaws works only on TH fittings .

Pressure and temperature ratings
Both profiles handle 10 bar maximum pressure. Both tolerate up to 95°C continuously. Short spikes to 110°C are acceptable. Brass press fittings have identical operating limits. Example: a U fitting and a TH fitting both work at 85°C water temperature .

Example: choosing for a residential system
A house has Uponor PEX pipes throughout. You need to add new connections. Brass press fittings with U-profile are correct here. Using TH-profile would cause leaks. Example: always match the fitting profile to the pipe system's specification .

Example: commercial building installation
A building uses Viega ProPress fittings system-wide. The contractor has TH-profile tools. Brass press fittings with TH-profile are required. U-profile fittings would not press correctly. Example: the tool investment determines which profile you standardize on.

Final comparison summary
U-profile and TH-profile brass press fittings differ in geometry, origin, and tooling. They are not cross-compatible for pressing. Choose based on your pipe system's specification. Use U-profile for Uponor and European systems. Use TH-profile for Viega and North American systems. Always verify the profile before purchasing brass press fittings. The wrong choice leads to leaks and failed inspections. Example: check your press tool's jaw markings before ordering fittings .
